Technical Specifications
*Applications in TIG, MIG/MAG, plasma welding, plasma cutting and shielding gas
*Complies with EN ISO 2503 standard (TSE, APRAGAZ)
*Easy readability with EN ISO 5171 compliant colored Ø63 mm gauges
*Stainless steel filter extends product lifespan
*Patented design with high-protection gauge housing
*Colored protection design indicating gas types
*Enhanced safety fuse system
*Flowmeter design with advanced pin system for precise flow adjustment
*Connection fitting suitable for Ø4 and Ø6 mm hoses
*Operating temperature (-20°C / +60°C)
*Forged brass body and chrome-plated cover design
*Use with heaters is recommended for mixed gas regulators



Gas Inlet Pressure :0-230 Bar/ 0-300 Bar
Gas Outlet Flow :0-30 L/Min
Working Standard :EN ISO 2503
Inlet\Outlet Connection :The Cylinder Connection is Made In Accordance with Each Country and Standard
SKU 5440F30-AU
Barcode # 8693752107428
Brand Yildiz Gas Equipment Australia
Shipping Weight 1.5000kg
Shipping Width 0.130m
Shipping Height 0.140m
Shipping Length 0.210m
